Page 7 of 14
Stand installation
The MF10 & MF15 are supplied mounted on floor standing stands that
incorporate filter baskets. The stand should be levelled using the adjustable feet. It is
possible to fix the stand to the floor, if required, by screwing through to holes in the feet.
The waste is discharged from the waste hose via a Filter Basket into the drain
tray of the stand, which has a 38mm waste pipe connection. This pipe may either
discharge into a gulley beneath the machine or it may be connected via a shallow seal
waste trap and fixed pipework into the waste water system of the building.
All electrical work must be carried out by a qualified electrician and in accordance
with the IET Codes of Practice. Before connecting, examine the rating plate attached to
the machine to ensure that the characteristics shown are correct for the supply
available. The peeler should be connected to a 30A isolator providing at least 3mm
separation in all poles, ensure that the isolator is accessible with the peeler in place.
The isolator should be fused at the ratings shown below:
The supply to the machine must also be protected by a 30mA RCD. A new mains
supply run to the machine should always be undertaken by an approved electrician.
The IET Codes of Practice must be observed.
The mains lead fitted to the machine is the minimum required for individual
connection to the mains supply. Site conditions may vary with additional length of cable
run, encapsulation in trunking, bunched with other cables etc. being required. Should
this apply, the qualified electrician must alter the lead accordingly in accordance with
the IET Codes of Practice.
WARNING: This machine must be earthed
The wires in the mains lead for single phase supply are coloured:
ELECTRICITY SUPPLY CONNECTION
