The wires in the mains lead for three phase supply are coloured:
The 3 phase machines do not have a neutral wire, if the supply has a neutral wire
isolate it and only wire the unit to the 3 phases and earth.
An equipotential bonding terminal is provided at the back of the unit near the cable
outlet for external earth bonding. Provision of an earth bond does not remove the
requirement for an earth in the electrical supply.
The water pipe is packed inside the machine for transit and should be fitted to the top of
the lid using the screws provided. The water supply pipe should be connected to an
adjacent cold water supply using a Lincat Inlet Hose Kit (Part No S58/062) or a 12mm
(1/2") bore hose.
PLEASE NOTE: these machines are fitted with a Type A air-break to prevent back
syphonage into the mains supply, but some local authorities may nevertheless require
connection to a storage cistern rather than direct to the mains supply.
This applies to UK installations, overseas customers should install the machine in
accordance with local regulations.
IF IN DOUBT, CHECK WITH YOUR LOCAL AUTHORITY
After making the electrical connection, switch on the machine, and ensure that the unit
will only run with the lid and the chute door closed. Then check that the direction of
rotation of the shaft is CLOCKWISE when viewed from above. The direction of rotation
of single phase units is set at the factory, if it is not rotating in the correct direction
contact Lincat. To change the direction of rotation of three phase units, switch off the
machine, isolate the supply and interchange any two phase wires.
