IMCA Mini RadaScan - Responder Specifications

28 IMCA M 229
MDL standard and multi-target
Kongsberg BCD
Marine Technologies custom strings
Rolls-Royce custom strings
VFD
2 lines 20 characters
Sensor Environmental conditions
Temperature range
-25ºC to +55ºC
Atmospheric conditions
All-weather
Water and Dust protection
Sealed, water-tight radome meets IP66
Sensor Dimensions
Diameter
500mm
Height
400mm
Weight
21kg
Dimensions (boxed)
620x620x730 mm
Weight (boxed)
63 kg
Mounting
4 bolts in base
Sensor Compliance
EN 60945 & EN301 843-1 (EMC)
EN 62388:2002, Annex B
ITU-R Recommendation RM. 1177 European Directive
2004/108/EC EMC: CE Certified
FCC Approved
12.3 Responder Specifications
Responder Technical details
Emission frequency
9.2-9.3 GHz
Power
 220V/110V mains adapter
 Rechargeable battery (30 days)
 Non-rechargeable power cell pack (12 months)
Antenna type
Unidirectional array
Azimuth angle
Up to 170º
Elevation angle
Up to +/-35º
Responder Environmental conditions
Temperature range
-25ºC to +55ºC (-40ºC option)
Atmospheric conditions
All-weather, explosive atmosphere
Water and dust protection
Sealed, water tight connector cap
Buoyancy
Floating design and tested for immersion up to 1m
Responder Dimensions
Dimension
170 x 305 x 128 mm
Weight
5 kg
Dimension (boxed)
480 x 380 x 210 mm
Weight (boxed)
11 kg
Mounting
Brackets
Responder Compliance
ATEX, UL certified
