ATTENTION!
If the machine cannot be installed respecting the criteria below, it is necessary to request the right
transformations from the manufacturer.
Please note that for proper use, operation, and maintenance, it is necessary to leave a free space of at least 500 mm from
the rear panel of the machine.
ATTENTION!
To perform ordinary and extraordinary maintenance, leave on both sides of the machine, a free space at least
equal to the length of the machine itself!
The ambient temperature must be between +5°C and +40°C.
The smooth operation of the machinery is guaranteed in environments where the residual humidity is not higher than
50% at a temperature of +40 ° C.
The machinery may not be installed at altitudes above 1000 m above sea level.
The degree of protection is IP 22.
The support surface must have a minimum capacity of 500 kg/m
2
: the load of the machinery can be considered static.
The machine must be placed in a well-ventilated room (by the laws in force).
In the room, an air exchange proportional to that subtracted from the operation of the machinery must be ensured.
The ventilation air must be taken directly from the outside, in an area far from sources of pollution, and the influx must
be guaranteed by permanent openings made on the walls of the room that give outwards. The calculation of the net total
free section must be conducted by the regulations in force on the subject.
ATTENTION!
The machine MUST NOT be installed outdoors, but in a CLOSED environment specifically built and used as a
laundry.
7. INDICATIONS ON SOUND EMISSION
The airborne noise produced by the machine produces an "A" weighted continuous sound pressure level of less than 70
dB.
8. FLUE GAS EXHAUST PIPE (ONLY FOR GAS MACHINES) AND WET AIR DUCT
The flue gas exhaust pipe (for machines with gas heating) must be made according to current regulations. In the case of
gas operation, the chimney must be spaced (at least 500 mm) from combustible or highly flammable materials by an air
gap or insulating materials. If this distance cannot be maintained, it is necessary to provide appropriate specific
protection for heat.
The flue gas exhaust pipe can have a maximum length of 15 meters (diameter 100 mm) and must be insulated or made
so that any condensate can be collected. For lengths longer than 15 meters, the Installer must contact the manufacturer.
The exhaust pipe, the connection to the chimney and the chimney must be made in compliance with local and national
rules and / or regulations in force. The use of rigid ducts is mandatory; the joints between the elements must be airtight
and all components must be resistant to temperature, condensation, and mechanical stress. Flues that are not adequately
sized or poorly shaped, amplify the noises of combustion and give rise to condensation problems. They can also
interfere with combustion parameters, favoring the formation of soot and scale. To avoid leakage of flue gas and noise,
the joints must be made hermetic, with materials (stucco, mastics, silicone preparations) resistant to high temperatures.
In case of connection to existing exhaust manifolds, the connection should never be made to "T", but always to "Y" (see
figures below).
