The assembly of a manifold to unify the exhaust pipe of several machines cannot be carried out for smoke outlets: the
smoke outlets must remain independent and flow outside the installation room.
For machines with electric heating, it is possible to supply a collector to unify the humid air outlets: do not make "T"
connections and consider the correct value of the collector section. If necessary, support an increase in the collector
section.
ATTENTION!
Wet air ducts and smoke evacuation ducts must never be joined.
ATTENTION!
The outlet of the exhaust pipe must not flow at human height and/or be directed towards residential units.
ATTENTION!
Instruct the user on the danger of tampering with the exhaust pipes and/or changing, plugging, obstructing, or
reducing the ventilation openings of the installation space.
ATTENTION!
Do not insert your hands objects inside the drain (size. 6). On this connection must be exclusively connected the
smoke evacuation chimney and humid air.
With regard to the dimensions and dimensions of the smoke and humid air exhausts, please refer to the attached
technical sheet.
9. ELECTRICAL CONNECTION
ATTENTION!
The electrical connection must be carried out by professionally qualified personnel and must meet the
requirements of current local and national rules and / or regulations.
