imilab V1 - Cleaning and Replacing Brushes

Cleaning the main brush
1. The main brush is a consumable material that should be
cleaned at least once a week. It is recommended to replace the
main brush every 6-12 months to ensure cleaning eect. Flip
the robot vacuum over and press the catch on the main brush
cover to remove the main brush cover and the main brush.
Note: Be careful when flipping the robot vacuum over to avoid
damage to the lidar.
Cleaning/replacing the side brush
1. Use a screwdriver to remove the screw on the side brush and
take the side brush out.
2. Attach the side brush after cleaning or replace it with a new
one.
Note: It is recommended to replace the side brush every 3-6
months to ensure cleaning eect.
2. Use a cleaning knife to cut away hairs that have entangled
on the main brush. Use the other end of the cleaning knife to
clean the main brush.
3. Fix back the main brush and main brush cover and secure
the catch.
Main brush cover
Remove
Install
Main brush
17 18
