14
Once the batteries are replaced, close the battery compartment lid, press the reset button (R) and reset the time as described
in chapter 8 (clock setting).
WIRING CONNECTIONS
Connect the wires of UNIT TO BE CONTROLLED to terminal 1 and 2 of the thermostat (see wiring diagram).
WARNING:
We strongly recommend that, while installing the thermostat, all safety instructions and laws in force be strictly followed.
U= load
1= common contact
2= Normally Open contact
3= Normally Closed contact
