- The CLOCK SETTING procedure may be start again at any given time by pressing the reset button (R).
9. PROGRAM SETTING
Only after the clock is set, the program can be set.
The thermostat is equipped with a series of micro-switches, with 24 little switches, one for each hour of the day.Therefore, the
program is the same for every day of the week. The setting is very simple: move up the switches (position “
T1✲”) for the
amount of hours you want the temperature set with the “sun
✲” knob (NORMAL temperature).On the contrary, lower the swit-
ches (position “
T2 ”), for the amount of hours you want the REDUCED temperature (selector 6°/16°C or 23°/26°C).
The set operating-program will be “graphically” displayed for an easy reading and a possible modification.
To ACTIVATE the program:
• Press the
F button and check if the symbol “ “ and the reading “OK-OK” are on display (fig.6).
17
(fig.5)
