20
display (fig.8).
NOTE:Pressing the F button when the thermostat is in
“override” at NORMAL temperature “T1”, it takes the unit
back to normal operation under the ACTIVE program, indi-
cated by the symbol “clock” ( ) and by the reading “OK-
OK”on the display.
13. SUMMER/WINTER
SETTING
The thermostat can be programmed for “summer” or “winter”
operation, whether is connected to the air conditioner or to the
boiler.
• Switch the selector on the “sun” position (
✲) for “summer”
mode or on the “igloo” position ( ) for “winter” mode (fig.9).
In both cases, either (
✲) or ( ) will appear on the display to
show which mode is on.
(fig.8)
