4. THERMOSTAT CONTROLS KEY
7
Reset button
Knob for normal
temperature “T1” setting
Reduced
temperature “T2”
selector
Summer (
✲ ) or winter ( )
mode selector
“Override”
button
Microswitches for current time
and operating program setting
