FIG. 15
SUMMER/WINTER SWITCH
On TA3-C, put the switch onto the position to set up the “summer” operation mode (air conditioning
system), or onto the “ ” position to set up the “winter” operation mode (heating system). (g.13 ” position to
set up the “winter” operation mode (heating system). (g.13)
FIG. 13
PROBLEM SOLVING
Problem
The system does not start
Possible cause
Wrong wiring
The set room temperaturehas been already reached
Switch on OFF position
Wrong setting ofsummer/winter switch
Solution
Check if the wiring connections to the thermostat terminals were carried out as per wiring diagram
