1.14 WATER HEATER COMPONENTS.

Key:

1 - Sealed chamber

2 - Fan

3 - DHW heat exchanger

4 - Ignition/detection electrode

5 - Gas valve

6 - Flue pressure switch

7 - Safety thermostat

8 - Flue hood

9 - DHW probe (hot water output)

10 - Combustion chamber

11 - Burner

12 - Gas manifold

13 - Flow limiter

14 - One-way valve

15 - Flow rate meter

16 - Domestic water inlet cock

17 - DHW probe (cold water input)
