Immergas CAESAR 14 3 E - Combustion Parameters

22 - IE
INSTALLATORUSERTECHNICIAN
3.14 COMBUSTION PARAMETERS.
Super Caesar 17 3 E.
METHANE (G20) BUTANE (G30) PROPANE (G31)
HEAT
OUTPUT
HEAT
OUTPUT
BURNER
GAS FLOW RATE
BURNER NOZZLES
PRESSURE
BURNER
GAS FLOW RATE
BURNER NOZZLES
PRESSURE
BURNER
GAS FLOW RATE
BURNER NOZZLES
PRESSURE
(kW) (kcal/h) (m
3
/h) (mbar) (mm H
2
O) (kg/h) (mbar) (mm H
2
O) (kg/h) (mbar) (mm H
2
O)
29.8 25628 3.56 12,50 127,5 2.66 28.50 290.6 2.62 36.60 373.2
29.0 24940 3.47 11,86 121,0 2.59 27.08 276.2 2.55 34.83 355.2
28.0 24080 3.36 11,10 113,2 2.50 25.37 258.7 2.46 32.70 333.4
27.0 23220 3.24 10,36 105,7 2.42 23.73 242.0 2.38 30.64 312.4
26.0 22360 3.13 9,66 98,5 2.33 22.15 225.9 2.30 28.66 292.3
25.0 21500 3.01 8,99 91,6 2.25 20.64 210.5 2.21 26.75 272.8
24.0 20640 2.90 8,34 85,0 2.17 19.19 195.7 2.13 24.92 254.1
23.0 19780 2.79 7,72 78,7 2.08 17.80 181.5 2.05 23.15 236.1
22.0 18920 2.68 7,13 72,7 2.00 16.46 167.8 1.97 21.45 218.7
21.0 18060 2.57 6,56 66,9 1.92 15.18 154.7 1.88 19.81 202.0
20.0 17200 2.46 6,02 61,4 1.83 13.95 142.2 1.80 18.23 185.9
19.0 16340 2.34 5,50 56,1 1.75 12.77 130.2 1.72 16.71 170.4
18.0 15480 2.23 5,01 51,1 1.67 11.64 118.7 1.64 15.24 155.4
17.0 14620 2.12 4,54 46,3 1.58 10.56 107.7 1.56 13.84 141.1
16.0 13760 2.01 4,10 41,8 1.50 9.54 97.2 1.47 12.49 127.3
15.0 12900 1.89 3,67 37,5 1.41 8.56 87.3 1.39 11.19 114.1
14.0 12040 1.78 3,27 33,4 1.33 7.63 77.8 1.31 9.95 101.5
13.0 11180 1.66 2,90 29,5 1.24 6.74 68.8 1.22 8.77 89.4
12.0 10320 1.55 2,54 25,9 1.15 5.91 60.3 1.14 7.63 77.8
11.0 9460 1.43 2,21 22,6 1.07 5.13 52.3 1.05 6.56 66.9
10.0 8600 1.31 1,91 19,5 0.98 4.39 44.8 0.96 5.53 56.4
9.0 7740 1.19 1,63 16,6 0.89 3.71 37.8 0.87 4.57 46.6
8.0 6880 1.07 1,37 14,0 0.80 3.08 31.4 0.78 3.66 37.3
7.7 6622 1.03 1,30 13,3 0.77 2.90 29.6 0.76 3.40 34.7
G20 G30 G31
Caesar 14 3 E
Gas nozzle diameter mm 1.35 0.81 0.81
Supply pressure mbar (mm H
2
O) 20 (204) 29 (296) 37 (377)
Flue ow rate at nominal heat output kg/h 55 57 59
Flue ow rate at min heat output kg/h 58 58 58
CO
2
at Nom Q./Min. % 7,20 / 2,10 8,10 / 2,42 7,64 / 2,40
CO with 0% O
2
at Nom Q /Min. ppm 70 / 145 78 / 174 40 / 172
NO
X
with 0% O
2
at Nom Q /Min. mg/kWh 177 / 109 200 / 60 220 / 75
Flue temperature at nominal output °C 171 171 163
Flue temperature at minimum output °C 113 113 113
Super Caesar 17 3 E
Gas nozzle diameter mm 1.35 0.80 0.80
Supply pressure mbar (mm H
2
O) 20 (204) 29 (296) 37 (377)
Flue ow rate at nominal heat output kg/h 71 69 71
Flue ow rate at min heat output kg/h 76 72 79
CO
2
at Nom Q./Min. % 6,80 / 1,70 8,11 / 2,10 7,85 / 1,91
CO with 0% O
2
at Nom Q /Min. ppm 40 / 190 75 / 234 54 / 223
NO
X
with 0% O
2
at Nom Q /Min. mg/kWh 135 / 107 210 / 65 230 / 90
Flue temperature at nominal output °C 157 164 161
Flue temperature at minimum output °C 92 97 90
