STEMkW Special ed 01/08 EOLO Mini kW Special
Technical DocumentationTechnical Documentation
Boiler circulator (1).
e pump works on the primary circuit return; it is part of the
pump body unit made in a composite material.
e automatic air vent (2) is housed directly on the body.
1
2
Primary exchanger (1).
It is a lamellar water-gas exchanger with copper tubes and ns
and at whose outlet (ow) the central heating NTC ow probe
(6) and the overtheating safety thermostat (2) are located.
e four pipes it is made of are connected in series (1).
It is connected to the circulator ow and to the primary circuit
ow by means of push-tted pipes (3) and O rings (5) and
locked with forks (4).
e exchangers of the 24 and 28 versions dier in the number
of ns (86 in the 24 version and 103 in the 28 version) and in the
dierent layout of the ow and return pipes (see drawing).
1
3
4
5
2
6
Flow
Return
1
3
4
5
2
6
Flow
Return
EOLO Mini 28 kW Special
EOLO Mini 24 kW Special
