Legend:
1 - Burner operating LED
2 - D.h.w. operating LED
3 - C.h. operating LED
4 - Temperature LED - Malfunction - circulation insu-
cient
5 - Temperature LED - Malfunction - ow probe
6 - Temperature LED - Malfunction - ignition block
Control Panel.
7 - Temperature LED - Malfunction - overheating block
8 - Temperature LED - Malfunction - ue pressure switch
9 - D.h.w. stand-by selector/Remote Control - D.h.w. and C.h.-
Reset
10 - D.h.w. temperature selector
11 - C.h. temperature selector
12 - Boiler gauge
