STEMkW Special ed 01/08 EOLO Mini kW Special
Technical Documentation
Technical Documentation
Coupling type vertical concentric kit Ø 80/125.
e exhaust pipe (80 mm Ø) is tted inside the aspiration
pipe (125 mm Ø).
Connection to the boiler is done using a ange (2) that, by
means of the 60/100-80/125 adapter (3) and necessary ex-
tensions, is connected to the specic aspiration and exhaust
terminal 80/125 with aluminium tile (6).
e maximum overall permitted length is 12.2 straight ver-
tical metres.
Coupling type vertical concentric kit Ø 60/100.
e exhaust pipe (60 mm Ø) is tted inside the aspiration
pipe (100 mm Ø).
Connection to the boiler is done using a ange (2) that, by
means of the necessary extensions, is connected to the speci-
c aspiration and exhaust terminal 60 /100 with aluminium
tile.
e maximum overall permitted length is 4.7 straight vertical
metres.
1
2
3
4
6
5
7
8
80/80 Ø coupling type separator kit.
Both pipes are 80 mm in diameter.
Connections to the boiler are done using the two specic
anges that allow discharge (4) from the centre tting and
aspiration (3) from one of the two side holes.
e maximum permitted length (aspiration + exhaust) is 33
straight horizontal metres and 41 straight vertical metres.
To avoid condensate problems, the exhaust pipe is limited to
a maximum of 5 metres.
NOTE: For the EOLO Mini 28 kW Special version it is
compulsory to install a diaphragm (10) inside the ange (3)
and before the aspiration pipe.
80/80 Ø insulated coupling type separator kit.
Both pipes are 80 mm in diameter.
Connections to the boiler are done using the two specic
anges that allow discharge (4) from the centre tting and
aspiration (3) from one of the two side holes.
Insulation is by way of the seals (6) which create an air gap
with the external concentric 125 mm Ø pipe.
e maximum permitted length is 33 straight metres (aspi-
ration + exhaust).
To avoid condensate problems, the exhaust pipe is limited to
a maximum of 12 metres.
NOTE: For the EOLO Mini 28 kW Special version it is
compulsory to install a diaphragm (10) inside the ange (3)
and before the aspiration pipe.
