EOLO SUPERIOR PLUS
COMBUSTION PARAMETERS
(with combustion air temperature 15 ºC)
G20 G30 G31
Nominal output fume mass flow kg/h 65 65 66
Minimum output fume mass flow kg/h 68 68 69
CO
2
at nominal output % 6.6 7.6 7.5
CO
2
at minimum output % 2.4 2.8 2.7
CO at 0% of O
2
at nominal output ppm 32 52 30
CO at 0% of O
2
at minimum output ppm 104 114 115
No
x
at 0% of O
2
at nominal output ppm 131 170 140
No
x
at 0% of O
2
at minimum output ppm 71 75 71
Fume temperature at nominal output ºC 118 110 114
Fume temperature at minimum outputs ºC 90 92 93
EOLO 24 SUPERIOR PLUS HEAT OUTPUT ADJUSTMENTS
NATURAL GAS (G20) BUTANE (G30) PROPANE (G31)
Heat
output
(Kcal/h)
Heat
output
(kW)
Burner gas
flow
(m
3
/h)
Burner nozzle
pressure
(mbar) (mm H
2
O)
Burner gas
flow
(kg/h)
Burner nozzle
pressure
(mbar) (mm H
2
O)
Burner gas
flow
(kg/h)
Burner nozzle
pressure
(mbar) (mm H
2
O)
24000 27.9 3.18 9.9 101 2.37 28.2 287 2.33 35.7 364
23000 26.7 3.05 9.0 92 2.27 26.1 266 2.24 32.8 334
22000 25.6 2.92 8.2 83 2.18 24.1 246 2.14 30.0 306
21000 24.4 2.79 7.4 75 2.08 22.2 226 2.05 27.5 280
20000 23.3 2.67 6.7 68 1.99 20.4 208 1.96 25.0 255
19000 22.1 2.54 6.0 61 1.89 18.6 190 1.87 22.7 232
18000 20.9 2.42 5.4 55 1.80 17.0 173 1.77 20.5 210
17000 19.8 2.29 4.8 49 1.71 15.4 157 1.68 18.5 189
16000 18.6 2.17 4.3 44 1.62 13.9 142 1.59 16.6 169
15000 17.4 2.05 3.8 39 1.52 12.4 127 1.50 14.8 151
14000 16.3 1.92 3.4 34 1.43 11.0 113 1.41 13.1 134
13000 15.1 1.80 3.0 30 1.34 9.7 99 1.32 11.6 118
12000 14.0 1.67 2.6 27 1.25 8.4 86 1.23 10.1 103
11000 12.8 1.55 2.3 23 1.15 7.2 74 1.13 8.8 90
10000 11.6 1.42 2.0 21 1.06 6.1 62 1.04 7.6 77
9000 10.5 1.29 1.8 18 0.96 5.0 51 0.95 6.5 66
