Anomalies signalling tables:
Sensors and variable inputs:
Description Fault type Code
External sensor Cuto 10-0
External sensor Short circuit 10-1
Boiler sensor Cuto 11-0
Boiler sensor Short circuit 11-1
Delivery sensor MC 1 Cuto 12-0
Delivery sensor MC 1 Short circuit 12-1
Domestic hot water sensor Cuto 13-0
Domestic hot water sensor Short circuit 13-1
Variable input VI2 Cuto 14-0
Variable input VI2 Short circuit 14-1
Variable input VI2 Anomalies signal 14-7
Variable input VI3 Cuto 15-0
Variable input VI3 Short circuit 15-1
Variable input VI3 Anomalies signal 15-7
Common delivery sensor Cuto 16-0
Common delivery sensor Short circuit 16-1
Solar delivery sensor Cuto 17-0
Solar delivery sensor Short circuit 17-1
Delivery sensor MC 2 Cuto 18-0
Delivery sensor MC 2 Short circuit 18-1
Solar return sensor Cuto 19-0
Solar return sensor Short circuit 19-1
Temperatures:
Boiler delivery temperature not reached 50-4
Boiler delivery temperature exceeded 50-5
D.h.w. circuit delivery temp. not reached 51-4
Delivery temperature MC 1 not reached 52-4
Delivery temperature MC 2 not reached 53-4
Room temperature DC not reached 54-4
Room temperature MC 1 not reached 55-4
Room temperature MC 2 not reached 56-4
BUS data:
Address addresses conict 70-0
Activity no signal 70-1
EEPROM 71-0
EEPROM faulty 71-1
Boiler errors:
Error block* E-XX
Error block* B-XX
* see the boiler instruction manual
Anomalies register.
e standard regulator is provided with an anomalies register
where up to ve errors can be stored. ese fault signals are vi-
sualized in the menu "alarm" together with date, time and type
of the error. Entering this menu protected by code; the most
recent fault is visualized, then turning the knob it is possible to
display all the 5 fault reports.
