VICTRIX PRO V2 EU
115
VICTRIX PRO
V2 35 EU
VICTRIX PRO
V2 55 EU
VICTRIX PRO
V2 60 EU
Maximum nominal heat input kW 34.9 51.0 59.9
Maximum nominal gas heat input
20% H2NG
kW 33.5 49,3 57.0
Min. heat input kW 3.9 5.4 7.8
Min. gas heat input 20% H2NG kW 3.6 5.3 7.5
Maximum useful heat output (80/60°C) kW 33.9 49.8 58.5
Maximum useful heat output (80/60°C)
gas 20% H2NG
kW 32,5 48,1 55,7
Min. useful heat output (80/60°C) kW 3,7 5.1 7.5
Min. useful heat output (80/60°C) gas 20%
H2NG
kW 3.4 5.0 7.2
Maximum useful heat output (50/30°C) kW 36,9 54.2 64.0
Maximum useful heat output (40/30°C) kW 37,6 54.5 64,9
Eciency at nominal heat output (80/60°C) % 97.0 97.6 97.7
Eciency at nominal heat output (50/30°C) % 105.8 106.2 106.8
Eciency at nominal heat output (40/30°C) % 107.7 106.8 108.3
Eciency at min. heat output (80/60°C) % 94,0 95.2 96.2
Eciency at min. heat output (50/30°C) % 105.7 106.5 106.6
Eciency at min. heat output (40/30°C) % 107.2 108.3 109,4
27 TECHNICAL DATA
Adjustable central heating temperature °C 15-90 15-90 15-90
System max. working temperature °C 95 95 95
System max. working pressure bar 4.4 4.4 4.4
Head available with 1000 l/h ow rate kPa (m c.a.) 58,0 (5,80) 68,0 (6,80) 111,0 (11,10)
Gas ow rate at METHANE burner (G20) m
3
/h from 0,41 to 3,69 from 0,57 to 5,40 from 0,83 to 6,34
Gas ow rate at LPG burner (G31) kg/h from 0,30 to 2,71 from 0,42 to 3,96 from 0,61 to 4,65
Useful heat output at Pn (η100)
ref. UNI EN 15502-1
% 109,8 109,5 109.7
Useful heat output at Pn (η30)
ref. UNI EN 15502-1
% 96.8 98.0 97.6
Electric power supply V/Hz 230 - 50 230 - 50 230 - 50
Nominal power absorption A 1 1.8 2.2
Installed electric power W 130 158 295
Fan max absorbed power W 45 65 95
Pump max absorbed power W 72 73 175
Power absorbed in stand-by W 5 6 6
Electric insulation rating IP X5D X5D X5D
Boiler water content litres 2.4 2.8 3.2
Weight of empty boiler kg 50 57 61
Technical note
e minimum and maximum head data (Pa) of the fan are displayed on pages 88 and 89
