VICTRIX PRO V2 EU
116
27.1 TECHNICAL DATA
VICTRIX PRO
V2 68 EU
VICTRIX PRO
V2 80 EU
VICTRIX PRO
V2 100 EU
Maximum nominal heat input kW 65.0 75.0 93.0
Maximum nominal heat input
gas 20% H2NG
kW 62.0 72.0 88.7
Min. heat input kW 7.8 7.8 10.1
Min. gas heat input 20% H2NG kW 7.5 7.5 9.4
Maximum useful heat output (80/60°C) kW 63.4 73,2 90,9
Maximum useful heat output (80/60°C)
gas 20% H2NG
kW 60.5 70.3 86,7
Min. useful heat output (80/60°C) kW 7.5 7.5 9.8
Min. useful heat output (80/60°C) gas 20%
H2NG
kW 7.2 7.2 9.1
Maximum useful heat output (50/30°C) kW 69.2 79.4 98,8
Maximum useful heat output (40/30°C) kW 70.1 79.4 100,6
Eciency at nominal heat output (80/60°C) % 97.5 97.6 97.7
Eciency at nominal heat output (50/30°C) % 106.5 105,9 106.2
Eciency at nominal heat output (40/30°C) % 107.8 105.8 108.2
Eciency at min. heat output (80/60°C) % 96.2 96.2 96.6
Eciency at min. heat output (50/30°C) % 106.6 106.6 107.3
Eciency at min. heat output (40/30°C) % 109,4 109,4 107.9
Adjustable central heating temperature °C 15-90 15-90 15-90
System max. working temperature °C 95 95 95
System max. working pressure bar 4.4 4.4 6
Head available with 2400 l/h ow rate kPa (m c.a.) 85,0 (8,50) 85,0 (8,50) 97,0 (9,70)
Gas ow rate at METHANE burner (G20) m
3
/h
from 0,83 to 6,88 from 0,83 to 7,94 from 1,07 to 9,84
Gas ow rate at LPG burner (G31) kg/h
from 0,61 to 5,05 from 0,61 to 5,83 from 0,78 to 7,22
Useful heat output at Pn (η100)
ref. UNI EN 15502-1
% 109,6 109,8 109,8
Useful heat output at Pn (η30)
ref. UNI EN 15502-1
% 97.7 98.0 98.0
Electric power supply V/Hz 230 - 50 230 - 50 230 - 50
Nominal power absorption A 2.3 2.5 2.7
Installed electric power W 300 320 330
Fan max absorbed power W 103 120 155
Pump max absorbed power W 175 175 175
Power absorbed in stand-by W 6 6 6
Electric insulation rating IP X5D X5D X5D
Boiler water content litres 3.2 3.2 9.0
Weight of empty boiler kg 61 61 95
Technical note
e minimum and maximum head data (Pa) of the fan are displayed on pages 88 and 89
