WATER VOLUMES IN KIT COUPLED WITH:
Model Primary circuit litre content Expansion vessel capacity (litres)
VICTRIX PRO V2 100 EU 15 2
VICTRIX PRO V2 120 EU 16 2
VICTRIX PRO V2 150 EU 18 2
VICTRIX PRO V2 180 EU 21 4
TECHNICAL DATA
Plate heat ex-
changer coupled
with
VICTRIX PRO
V2 EU (kW)
No.
plates
Maximum
managed
power
(kW)
Flow rate
Primary
(m
3
/h)
M/R 80°/60°
Flow rate
Secondary
(m
3
/h)
M/R 70°/55°
p (m.w.c.) Weight
of heat
exchanger
only (kg)
Primary
circuit
T 20°C
Secondary
circuit
T 15°C
100
110 180
4.3 5.7 0.20 0.43
9.9
120 5.1 6.9 0.29 0.63
150 6.4 8.6 0.50 0.99
180 7.3 9.7 0.60 1.25
Plate heat ex-
changer coupled
with
VICTRIX PRO
V2 EU (kW)
No.
plates
Maximum
managed
power
(kW)
Flow rate
Primary
(m
3
/h)
M/R 80°/65°
Flow rate
Secondary
(m
3
/h)
M/R 70°/60°
p (m.w.c.) Weight
of heat
exchanger
only (kg)
Primary
circuit
T 15°C
Secondary
circuit
T 10°C
100
110 180
5.7 8.6 0.44 0.98
9.9
120 6.9 10.3 0.64 1.40
150 8.6 12.9 1.0 2.20
180 9.7 15.5 1.27 3.18
12.4 PLATE HEAT EXCHANGER KIT TECHNICAL DATA
FOR VICTRIX PRO V2 100  120  150  180 EU SINGLE BOILER CODE: 3.033677
0
0,12
0,3
0,63
0,98
1,4
2,2
3,18
0
0,5
1
1,5
2
2,5
3
3,5
0 3 4,7 6,8 8,6 10,3 12,9 15,5
Perdite di carico (m.c.a.)
Portata (m3/h)
Grafico perdite di carico scambiatore
Victrix Pro 100-120-150-180 V2
(∆T 15° Lato caldaia/∆T 10° Lato impianto)
Heat exchanger head loss chart
VICTRIX PRO V2 100 - 120 - 150 - 180 EU
(T 15° Boiler side/T 10° System side)
Flow rate (m3/h)
Head losses (mmw.c.)
