VICTRIX PRO V2 35 - 55 - 60 - 68 - 80 EU
42
is kit is composed of just two gaskets 44x34x2 (1) and two
insulated pipes (2), to compensate for the variation in the
centre distances between ow and return on VICTRIX PRO
V2 35 - 55 - 60 - 68 - 80 EU boilers, which is 300 mm in com-
parison to the centre distance between ow and return on the
rst range of high output wall-hung boilers (e.G. VICTRIX
50-75), which is 390 mm.
Accordingly, it is possible to install VICTRIX PRO V2 35 -
55 - 60 - 68 - 80 EU models in place of the models from the
rst range of VICTRIX 50-75 wall-hung boilers in single
conguration.
e elements illustrated in the gure and any INAIL safety kit
for single boilers must be installed according to the relative
documents of reference.
15 VICTRIX PRO V2 35  55 - 60 - 68 - 80 EU ADAPTER KIT TO REPLACE FIRST
RANGE OF WALLHUNG BOILERS IN SINGLE CONFIGURATION CODE: 3.023966
KEY:
1 - 44x34x2 gasket
2 - Insulated adaptation pipe
5 - Generator
M - Flow
R - Return
1
M
R
1
5
2
2
