Immergas VICTRIX PRO V2 EU - Page 57

VICTRIX PRO V2 35 - 55 - 60 - 68 - 80 EU
57
WATER VOLUMES IN KIT COUPLED WITH:
Model Primary circuit litre
content
Expansion vessel capaci-
ty (litres)
Max system side heat
exchanger pressure (bar)
n° 2 VICTRIX PRO V2 35 EU 25 4 25
n° 3 VICTRIX PRO V2 35 EU 34 4 25
n° 4 VICTRIX PRO V2 35 EU 43 8 25
n° 5 VICTRIX PRO V2 35 EU 52 8 25
n° 2 VICTRIX PRO V2 55 EU 26 4 25
n° 3 VICTRIX PRO V2 55 EU 35 4 25
n° 4 VICTRIX PRO V2 55 EU 45 8 25
n° 5 VICTRIX PRO V2 55 EU 54 8 25
n° 2 VICTRIX PRO V2 606880 EU 27 4 25
n° 3 VICTRIX PRO V2 606880 EU 37 4 25
n° 4 VICTRIX PRO V2 606880 EU 46 8 25
n° 5 VICTRIX PRO V2 606880 EU 56 8 25
TECHNICAL DATA
Plate heat ex-
changer coupled
with
VICTRIX PRO
V2 EU (kW)
No.
plates
Maximum
managed
power
(kW)
Flow rate
Primary
(m
3
/h)
M/R 80°/60°
Flow rate
Secondary
(m
3
/h)
M/R 70°/55°
p (m.w.c.) Weight
of heat
exchanger
only (kg)
Primary
circuit
T 20°C
Secondary
circuit
T 15°C
175
90 400
7.6 10.0 0.23 0.4
31.3
200 8.6 11.5 0.3 0.52
250 10.7 14.3 0.46 0.82
275 11.8 15.7 0.6 0.99
300 12.9 17.2 0.67 1.18
350 15.0 20.0 0.9 1.6
400 17.2 22.9 1.2 2.1
Plate heat ex-
changer coupled
with
VICTRIX PRO
V2 EU (kW)
No.
plates
Maximum
managed
power
(kW)
Flow rate
Primary
(m
3
/h)
M/R 80°/65°
Flow rate
Secondary
(m
3
/h)
M/R 70°/60°
p (m.w.c.) Weight
of heat
exchanger
only (kg)
Primary
circuit
T 15°C
Secondary
circuit
T 10°C
175
90 400
10.0 15.0 0.41 0.94
31.3
200 11.5 17.2 0.53 1.23
250 14.3 21.5 0.83 1.91
275 15.7 23.6 1.0 2.32
300 17.2 25.8 1.2 2.76
350 20.0 30.0 1.63 3.75
400 22.9 34.4 2.25 4.9
20.2 PLATE HEAT EXCHANGER KIT ON VICTRIX PRO V2 35  55  60  68  80 EU
MODULES IN SET INSTALLATION TECHNICAL DATA CODE: 3.033678
