VICTRIX PRO V2 EU
87
24.9 TOP COVER KIT IPX5D
IPX5D COVER KIT
CODE: 3.033670
Models:
VICTRIX PRO V2 35 EU
VICTRIX PRO V2 55 EU
VICTRIX PRO V2 60 EU
VICTRIX PRO V2 68 EU
VICTRIX PRO V2 80 EU
Conguration type B.
Using the relevant cover kit, direct air intake is possible and ue gas is exhausted into a single chimney or directly to the out-
side. In this conguration the appliance can be installed in a completely open place. e generator in this type B open cham-
ber and fan assisted conguration can be classied as follows:
- the ue gas exhaust must be connected to a single chimney or ducted directly to the external atmosphere via a vertical ter-
minal for direct exhaust (B
23
) or via an Immergas ducting system (B
53
) for the available models;
- B
23p
, B
53p
: type B
23
and B
53
installation with exhaust system designed to operate with positive pressure (check the head data
of the fan of each model on the following pages).
65
175
IPX5D COVER KIT
CODE: 3.033671
Models:
VICTRIX PRO V2 100 EU
VICTRIX PRO V2 120 EU
IPX5D COVER KIT
CODE: 3.033672
Model:
VICTRIX PRO V2 150 EU
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
7
8
9
2
3
4
5
6
11
12
13
14
10
1
2
3
6
4
5
10
11
12
13
9
7
8
154
IPX5D COVER KIT
CODE: 3.033689
Model:
VICTRIX PRO V2 180 EU
Key:
1 - ermoformed cover
2 - Air vent gasket
3 - Air vent gasket locking plate
4 - Flue exhaust gasket
5 - Flue exhaust gasket locking ange
6 - Stainless steel clip for ue gas seal
7 - Manhole seal
8 - Sheet metal manhole cover
9 - Self-threading screws
