VICTRIX PRO V2 EU
88
24.10 FAN HEAD AND MAXIMUM LENGTHS
e maximum head of the fan refers to the ue outlet above
the generator. Dimensioning of a chimney/ducted pipe can
be carried out in positive or negative pressure. To calculate
the length of the ue, simply add the corresponding “length
equivalent to 1 m of pipe” value for each component to be
used until the maximum allowed length for each product is
reached. ese data are provided in the specic technical doc-
umentation supplied with each “Use and maintenance booklet”.
VICTRIX PRO V2 35 EU
TYPICAL INSTALLATION: MAXIMUM LENGTH:
Head in variable ue gas outlet from 1 to 90 (Pa)
--
Concentric Ø 80/125 (mm) C13 (horizontal+curve) C33 (vertical)
15 (m)
Split Ø 80/80 (mm)
C43 - C53 - C83 (split)
30 (m)
B23 - B23p - B53 - B53p
30 (m) - with Clapet valve 15 (m)
Flue exhaust only Ø 80 (mm) C5 C53 (A: 1c+1m - S: 1c+1m+1c)
30 (m)
Flue exhaust only Ø 80 (mm) ex C53 (A: 1c+1m - S: 1c+1m+1c+ad.)
12 (m)
VICTRIX PRO V2 55 EU
TYPICAL INSTALLATION: MAXIMUM LENGTH:
Head in variable ue gas outlet from 2 to 190 (Pa)
--
Concentric Ø 80/125 (mm) C13 (horizontal+curve) C33 (vertical)
15 (m)
Split Ø 80/80 (mm)
C43 - C53 - C83 (split)
30 (m)
B23 - B23p - B53 - B53p
25 (m) - with Clapet valve 15 (m)
Flue exhaust only Ø 80 (mm) C5 C53 (A: 1c+1m - S: 1c+1m+1c)
30 (m)
Flue exhaust only Ø 80 (mm) ex C53 (A: 1c+1m - S: 1c+1m+1c+ad.)
12 (m)
VICTRIX PRO V2 60 - 68 - 80 EU
TYPICAL INSTALLATION: MAXIMUM LENGTH:
Head in variable ue gas outlet from 3 to 295 (Pa)
--
Concentric Ø 80/125 (mm) C13 (horizontal+curve) C33 (vertical)
10 (m)
Split Ø 80/80 (mm)
C43 - C53 - C83 (split)
20 (m)
B23 - B23p - B53 - B53p
20 (m) - with Clapet valve 10 (m)
Flue exhaust only Ø 80 (mm) C5 C53 (A: 1c+1m - S: 1c+1m+1c)
20 (m)
Flue exhaust only Ø 80 (mm) ex C53 (A: 1c+1m - S: 1c+1m+1c+ad.)
8 (m)
VICTRIX PRO V2 100 EU
TYPICAL INSTALLATION: MAXIMUM LENGTH:
Head in variable ue gas outlet from 3 to 230 (Pa)
--
Concentric Ø 110/160 (mm) C13 (horizontal+curve) C33 (vertical)
10 (m)
Split Ø 100/100 (mm)
C43 - C53 - C83 (split)
25 (m)
B23 - B23p - B53 - B53p
20 (m) - with Clapet valve 10 (m)
Flue exhaust only Ø 100 (mm) C5 C53 (A: 1c+1m - S: 1c+1m+1c)
20 (m)
VICTRIX PRO V2 120 EU
TYPICAL INSTALLATION: MAXIMUM LENGTH:
Head in variable ue gas outlet from 4 to 360 (Pa)
--
Concentric Ø 110/160 (mm) C13 (horizontal+curve) C33 (vertical)
10 (m)
Split Ø 100/100 (mm)
C43 - C53 - C83 (split)
25 (m)
B23 - B23p - B53 - B53p
20 (m) - with Clapet valve 9 (m)
Flue exhaust only Ø 100 (mm) C5 C53 (A: 1c+1m - S: 1c+1m+1c)
20 (m)
