VICTRIX PRO V2 EU
89
e Immergas Ø 80 mm system for exible ducting of existing
chimneys is made up from a series of components, identied
as individual kits, which can be assembled depending on the
specic installation requirements. is system is supplied in
a conguration that envisions an ascending 87° input bend,
then continuing vertically with the Ø 80 exible hose and the
exhaust terminal. e ducted tube is inspected at the mouth
of the boiler, via the relevant hatch.
e kit is made up from a 12 m exible hose. If the hose is too
short it can be joined to other pieces via the relevant adapters.
A centring spacer must however be inserted every now and
again, which via extendible ns, allows the pipe to stay in the
centre of the ue.
e maximum length for this ducting system is:
VICTRIX PRO V2 35 EU = 12 m
VICTRIX PRO V2 55 EU = 12 m
VICTRIX PRO V2 60 - 68 - 80 EU = 8 m
is length is obtained by considering:
- 1 Ø 80 mm 90° bend for connection to the boiler (intake);
- 1 m of Ø 80 mm pipe (in intake) with grid;
- 1 Ø 80 mm 90° bend for connection to the boiler (exhaust);
- 1 m pipe Ø 80 mm (in exhaust);
- the Ø 80 mm bend support;
- the vertical terminal kit for ducting Ø 80/125.
It is important to highlight that:
- in all cases it is a system to which a unique appliance can
be coupled;
- the system can only be coupled with condensing applianc-
es.
24.11 FLEXIBLE DUCTING SYSTEM Ø 80 OPTIONAL
VICTRIX PRO V2 35  55  60  68  80 EU
VICTRIX PRO V2 150 EU
TYPICAL INSTALLATION: MAXIMUM LENGTH:
Head in variable ue gas outlet from 16 to 350 (Pa)
--
Concentric Ø 110/160 (mm) C13 (horizontal+curve) C33 (vertical)
5 (m)
Split Ø 100/100 (mm)
C43 - C53 - C83 (split)
20 (m)
B23 - B23p - B53 - B53p
10 (m) - with Clapet valve 3 (m)
Flue exhaust only Ø 100 (mm) C5 C53 (A: 1c+1m - S: 1c+1m+1c)
10 (m)
VICTRIX PRO V2 180 EU
TYPICAL INSTALLATION: MAXIMUM LENGTH:
Head in variable ue gas outlet from 1 to 30 (Pa)
--
Split Ø 160/160 (mm)
C43 - C53 - C83 (split)
8 (m)
B23 - B23p
8 (m)
Flue exhaust only Ø 160 (mm) C5 C53 (A: 1c+1m - S: 1c+1m+1c)
8 (m)
