VICTRIX PRO V2 35 - 55 - 60 - 68 - 80 EU
90
8
3
5
THE KIT INCLUDES:
3 - Clapet valve Ø 80
5 - Additional Ø 160 module manifold
8 - Additional Ø 80 module manifold
25.1 FLUE EXHAUST MANIFOLD KIT Ø 160 WITH FLUE ADJUSTING DEVICE
TO EXPAND VICTRIX PRO V2 35  55  60  68  80 EU CODE: 3.034258
25 FLUE EXHAUST MANIFOLD KIT Ø 160 WITH
VICTRIX PRO V2 35  55  60  68  80 EU FLUE ADJUSTING DEVICE CODE: 3.034257
Modules
160 Ø Flue manifold kit
code: 3.034257
160 Ø Flue manifold kit for
expansion code 3.034258
2 VICTRIX PRO 35-55-60-68-80 V2 N° 1 --
3 VICTRIX PRO 35-55-60-68-80 V2 N° 1 N° 1
4 VICTRIX PRO 35-55-60-68-80 V2 N° 1 N° 2
5 VICTRIX PRO 35-55-60-68-80 V2 N° 1 N° 3
THE KIT INCLUDES:
1 - 1st Ø 80 Module connection
2 - 2nd Ø 80 Module connection
3 - Clapet valve Ø 80
4 - 1st Ø 160 Module manifold
5 - 2nd Ø 160 Module manifold
6 - Manifold for initial section Ø 160
7 - Drain trap unit
1
2
3
3
5
4
6
7
