VICTRIX PRO V2 100 - 120 - 150 EU
92
8
3
5
9
10
THE KIT INCLUDES:
3 - Clapet valve Ø 125
5 - Additional Ø 200-250 module manifold
8 - Additional Ø 110-125 module manifold
9 - Drain trap unit
10 - Manifold for initial section Ø 250
8
3
5
25.5 FLUE EXHAUST MANIFOLD KIT Ø 250 WITH FLUE ADJUSTING DEVICES
TO EXPAND 5
TH
VICTRIX PRO V2 150 EU CODE: 3.034262
25.4 FLUE EXHAUST MANIFOLD KIT Ø 250 WITH FLUE ADJUSTING DEVICES
TO EXPAND 4
TH
ICTRIX PRO V2 150 EU CODE: 3.034261
Modules
Flue manifold kit
Ø 200
code: 3.034259
Flue manifold kit
Ø 200 extension
code: 3.034260
Flue manifold kit
Ø 250 extension
code: 3.034261
Flue manifold kit
Ø 250 extension
code: 3.034262
2 VICTRIX PRO V2 150 EU N° 1 -- -- --
3 VICTRIX PRO V2 150 EU N° 1 N° 1 -- --
4 VICTRIX PRO V2 150 EU N° 1 N° 1 N° 1 --
5 VICTRIX PRO V2 150 EU N° 1 N° 1 N° 1 N° 1
THE KIT INCLUDES:
3 - Clapet valve Ø 125
5 - Additional Ø 250 module manifold
8 - Additional Ø 110-125 module manifold
