VICTRIX PRO V2 EU
95
KEY:
A2 - Circuit board
A4 - Display board
A25 - CLIP-IN (Optional)
A27 - Cascade and zone regulator;
A37 - Connection sheet (loads)
A38 - Connection card (signals)
B1-2 - System ow side probe (optional)
B2 - DHW probe (optional)
B3 - Low temperature ow probe (optional)
B4 - External probe (Optional)
E2 - Detection electrode
F5 - Phase fuse
F1 - Phase fuse
F2 - Neutral fuse
F4: - Phase fuse
K1 - Gas valve relay (Line)
K5 - Gas valve relay (Neutral)
K3 - Igniter relay
K70 - Multifunction relay
P1 - SW update (iXTool)
P3 - Pin (1&2) Communication jumper (Do not remove)
S1 - Main switch
S20-1 - Zone 1 room thermostat (optional)
S20-2 - Zone 2 room thermostat (optional)
S50 - DHW ermostat/Contact
X12 - Soware Update (iXTool)
X40 - Room thermostat jumper
Y1 - Gas valve
Z1 - Antijamming lter
Maximum loads on Relays of boards A2 and A4
Multifunction relay Voltage Current cosφ
From factory settings, K70 relays do
not perform any functions.
Insert an optional external relay to
drive each load.
K70-A1
K70-A2
K70-A3
K70-A4
K70-A5
230 Vac < 0.1 A ≥ 0,6
K70-A6
K70-A7
Potential-free contact (230 Vac
max)
< 0.1 A ≥ 0,6
- Remove X40 bridge in case of connection:
• Cascade and zone regulator;
• 0-10V signal;
• BMS;
• BUS OT;
• some types of central heating demand.
- For low-temperature zones, insert a safety thermostat in series with the relative zone pump.
- Make sure that the Openerm thermostat is compatible with the appliance.
- If the 0-10V input is enabled by means of the specic parameter, insert a 4,7 kohm resistance on terminals Y and Z.
ELECTRICAL CONNECTIONS (SIGNALS)
Components
Cable gauge (mm
2
)
Maximum length
(m)
Minimum Maximum
* B1-2
* B2
* B3
* S50
* 0 -10V
0.5 1.5 25 (2x25)
* B4
* S20-1
* S20-2
* Openerm
0.5 1.5 50 (2x50)
* External reset 0.5 1.5 10 (2x10)
* A27 J-Y(ST)Y 2x0.6 50 (2x50)
N.B.: e new electronics of VICTRIX PRO V2 EU can now control up to 15 thermal modules in simple cascade! It can also
completely independently manage up to 2 zones of the thermal system (1 direct and 1 mixed, if any) and1 DHW production
circuit.
