ImpediMed SFB7 - User Manual

Other manuals for ImpediMed SFB7

Questions and Answers

L
Lawrence SmithAug 8, 2025
What to do if ImpediMed SFB7 Medical Equipment shows 'Out of Range Check Leads and Electrodes'?
- J
  Joseph BlairAug 8, 2025
  If the ImpediMed Medical Equipment displays 'Out of Range Check Leads and Electrodes' or the reading seems incorrect, it indicates incorrect device setup. Here's what to check: * Verify leads are correctly fitted according to color codes. * Ensure leads are properly inserted into lead sockets. * Check for lead damage or tangling. * Confirm leads are correctly inserted into alligator clips. * Make sure alligator clips are securely attached to electrodes. * Use fresh electrodes. * Perform a calibration check to identify device faults, ensuring correct color coding and snug lead insertion into the test cell.
J
Jay CainAug 13, 2025
Why is there no display when my ImpediMed Medical Equipment SFB7 is switched on?
- D
  Danielle GriffinAug 13, 2025
  If your ImpediMed Medical Equipment SFB7 shows no display when switched on, the possible causes are: * Low battery power. * No external power. To resolve this: 1. Attach an external power pack and try again. 2. If the external power pack is already attached, ensure it is properly plugged in and switched on.
R
robert01Aug 17, 2025
How to fix ImpediMed SFB7 when it stops responding to touch screen?
- D
  Danielle BeanAug 17, 2025
  If your ImpediMed Medical Equipment stops responding to touch screen commands, it may be due to an internal software fault. Try powering the device off and then on again. Report the fault to ImpediMed.
R
Rebecca ClarkAug 21, 2025
What to do if ImpediMed SFB7 Medical Equipment shows "Out of Range Check Leads and Electrodes"?
- T
  Timothy VillarrealAug 21, 2025
  If the message "Out of Range Check Leads and Electrodes" appears on the screen, or the reading seems incorrect, it may be due to an incorrect device setup. To resolve this, follow these steps: 1. Ensure the leads are correctly fitted according to the color coding. 2. Make sure the leads are properly inserted into the lead sockets. 3. Check that the leads are not damaged or tangled. 4. Verify the leads are properly inserted into the alligator clips. 5. Ensure the alligator clips are securely attached to the electrodes. 6. Use fresh electrodes. 7. Perform a calibration check to determine if the device is faulty. 8. If performing the calibration check, ensure the color coding is correct and the leads are pushed snugly into the test cell.
T
Tommy CraneAug 25, 2025
Why does ImpediMed SFB7 Medical Equipment stop responding to touch screen commands?
- K
  Kim BoothAug 26, 2025
  If your ImpediMed Medical Equipment device stops responding to touch screen commands, it might be due to an internal software fault. Try powering the device off and then on again. If the issue persists, report the fault to ImpediMed.
E
Eric TapiaAug 29, 2025
How to fix no display on ImpediMed Medical Equipment SFB7?
- J
  josephfordAug 29, 2025
  If there is no display when your ImpediMed Medical Equipment SFB7 is switched ON, it could be due to low battery power or a lack of external power. First, try attaching an external power pack. If one is already attached, ensure it is properly plugged in and switched on.
L
Laura FrancoSep 3, 2025
What does it mean if the power light is blinking on ImpediMed Medical Equipment?
- S
  Sergio NguyenSep 3, 2025
  If the power light on your ImpediMed Medical Equipment is blinking, red, or orange, this is normal behavior. Please refer to the section titled "Battery Status Indicator" for more information.

The ImpediMed SFB7 is a portable, battery-powered device designed for the assessment of body composition using bioelectrical impedance analysis (BIA). It offers a rapid, reliable, non-invasive, and cost-effective method for measuring body composition parameters such as fat-free mass, fat mass, and intra-/extracellular fluid. The device operates by measuring how easily electrical currents move through the body, as fat offers more resistance than lean tissue due which contains most of the body's water.

Function Description:

The ImpediMed SFB7 functions in two primary modes: Bioimpedance Spectroscopy (BIS) and Selected Frequencies Bioimpedance (SFBI).

BIS Mode: This mode measures bioimpedance parameters over a broad frequency range of 4-1000 kHz, utilizing 256 data points to provide a true bioimpedance spectroscopy. On-screen graphs display the measured data in the form of a Cole-Cole plot, which visually represents reactance versus resistance. This plot helps indicate a valid measurement, with the absence of scattered data points and a well-fit Cole-Cole plot signifying noise-free data. The BIS mode also determines the characteristic frequency for the subject and total cell membrane capacitance, which are then used in algorithms to estimate body water and fat-free mass. Additionally, resistance versus frequency and reactance versus frequency plots are provided as visual representations of the measured bioimpedance data.
SFBI Mode: This mode also measures bioimpedance parameters over a frequency range of 4-1000 kHz but uses selected frequencies. There are 8 selectable frequencies, including 5 fixed frequencies (5, 10, 50, 100, 500 kHz) and 3 user-definable frequencies within the available range. Users can also specify the number of measurements to be taken and the measurement interval. The SFBI function is designed to allow users to compute and present body composition estimates using published algorithms.

Important Technical Specifications:

Measurement Range: 4-1000 kHz (256 data points in BIS mode).
Fixed Frequencies (SFBI): 5, 10, 50, 100, 500 kHz.
User-Definable Frequencies (SFBI): 3 frequencies within the available range.
Power Source: Portable battery-powered device with an internally installed rechargeable Lithium-ion battery. Recharging is done via a power module and main power cable.
Calibration Check: The device includes a test cell for calibration checks, ensuring accuracy with specific Rzero (604 ± 7 ohms) and Rinf (403 ± 5 ohms) readings.
Data Storage: BIS and SFBI measurement data are stored on board. BIS measurement data is retrievable via Ethernet.
Connectivity: Data transfer to a PC for analysis requires an AMD-Tek or Swann USB-Ethernet adapter and a RED Ethernet crossover cable.
Display: Touch screen interface for operation, with a stylus pen provided for interaction.
Automatic Shutdown: The device automatically shuts off after a period of inactivity.

Usage Features:

User Interface: The device features a touch screen for navigation and input, with a stylus pen recommended for making selections. The main menu provides options for "Measure," "Setup," "Test," and "Files."
Battery Status Indicator: An LED indicator on the device displays the battery status, with different colors and flicking patterns indicating various states such as off, charging, operational, near flat, flat, battery charger fault, or battery voltage detection fault.
Measurement Settings: Users can select single or continuous measurements, or several measurements spaced at a selected interval. The number of measurements and interval can be adjusted via arrow buttons or a keypad.
Patient Data Entry: Participant ID and other patient details can be entered directly on the device via the touch screen.
Electrode Placement: Specific anatomical locations are provided for electrode placement (wrist next to the ulnar head, dorsal surface of the hand, dorsal surface of the foot, and ankle at the level of medial and lateral malleoli). Electrodes should be placed 5 cm apart, center to center, with tabs pointing away from the body.
Lead Connection: Color-coded leads (yellow, red, blue, black) connect to corresponding colors on the back of the device and to the electrodes. Alligator clips are used to attach leads to electrode tabs.
Data Retrieval and Export: Files can be viewed and sorted by name or date/time on the device. Data can be exported to a PC using the provided USB-Ethernet adapter and crossover cable, for analysis with Biolmp Body Composition Analysis software. Uploaded files are automatically deleted from the device after confirmation of receipt.
Contraindications: The device must not be used on participants with active implanted medical devices (e.g., cardiac pacemakers, defibrillators, electronic life support devices), those undergoing external defibrillation, or pregnant individuals (as it has not been clinically validated for this group). Participants should also avoid excessive exercise and alcohol consumption prior to measurement, and certain conditions like menstruation, diuretic use, renal or heart failure can affect body water concentration.

Maintenance Features:

Cleaning: The SFB7 device should be cleaned with a dry, clean cloth only. Leads can be cleaned with a damp cloth if required. The touch screen should be cleaned with a soft damp cloth, avoiding direct liquids.
Care of Leads: Leads should ideally remain connected to the device to prolong their life. They should not be wound tightly, crinkled, or twisted to prevent damage to internal wires. If leads appear damaged, contact ImpediMed or a licensed distributor for replacements.
Electrode Care: Electrodes are single-use and should be discarded after use. Unused electrodes should be resealed in their pouch and stored in a cool, dry place to prevent gel dehydration. They should be used by their expiry date, and electrodes with dry or non-pliable/sticky conductive adhesive should not be used.
Storage: When not in use, the SFB7 should be kept in its carry case. It should be protected from water, impact, excessive heat, and direct sunlight.
Power Adapter: Only the supplied Amtex 9940 power adapter should be used for recharging to avoid electrocution risks.
Pre-measurement Check: The device should be unplugged from the recharging unit before use to avoid noise contamination.
Troubleshooting: A troubleshooting guide is provided to address common issues such as no display, "Out of Range Check Leads and Electrodes" messages, device unresponsiveness, or power light indicators, offering solutions ranging from checking connections and battery status to performing calibration checks or contacting ImpediMed for internal software faults.
No User-Adjustable Parts: The device does not contain user-adjustable parts and should not be disassembled.

ImpediMed SFB7 Specifications

General

Brand	ImpediMed
Model	SFB7
Category	Medical Equipment
Language	English
