12.2.4.1 Always use the stylus pen provided to operate the
touch screen. Use the rubber end of the stylus pen to
operate Imp SFB7 touch screen.
12.2.4.2 If necessary clean the touch screen with a soft
damp cloth, and do not use any liquids directly.
13 Troubleshooting
If the user encounters any problems, prior, or during testing, they can refer to the table
below.
The device stops responding
to touch screen commands.
Power light is blinking.
Or
Power light is red.
Or
Power light is orange.
Refer to section "Battery Status
Indicator."
1. Power the device off. Power the
device on.
2. Report the fault to ImpediMed.
1. Ensure the leads have been correctly
fitted according to the colour coding.
2. Ensure the leads are inserted properly
into the lead sockets.
3. Ensure the leads are not damaged or
tangled.
4. Ensure the lead are properly inserted
into the alligator clips.
5. Ensure the alligator clips are securly
attached to the electrodes.
6. Ensure the electrodes are fresh.
7. Perform the calibration check to
determine if the device is faulty.
8. If performing the calibration check,
ensure the colour coding is correct and
the leads are pushed snugly into the test
cell.
The message "Out of Range
Check Leads and Electrodes"
is displayed on the screen.
Or
The reading is obviously
incorrect.
The device is not correctly set up.
1. Attach external power pack and try
again.
2. If external power pack is attached,
check that power pack is plugged in and
switched on.
1. Battery power is low.
2.No external power.
No display when SFB7 is
switched ON.
