10.15 Predetermined measurement settings (e.g. number of measures to be
taken and at what interval) are set to the following, but can be modified at
this stage:
Measurement: interval
Interval(s): 10
Number: 3
10.16 Click “Measure”.
10.17 Click “Start”. Once measurements are completed (based on
predetermined settings) the device will say “Ready” at the top. Data is
automatically saved.
10.18 Press “Exit”, then “Back” 2 times to go back to the main menu.
11 Data Retrieval
11.1 Reading data from device
11.1.1 Press “Files” from the main menu.
11.1.2 Use the arrow buttons to navigate the file list.
11.1.3 The selected file can be viewed by touching “View File”.
11.1.4 Press “More…” button will display a Cole-Cole plot.
11.1.5 Files can be sorted by name or date and time. Touch either the “Name
Sort” or “Date Sort” button.
11.2 Exporting data from device
NOTE: When the file storage memory on the device is full, the device stops taking
measurements and displays the “File system full remove files to make space” screen. In
order to continue taking measurements, transfer files on to a PC loaded with Biolmp
Body Composition Analysis software or delete the files which are not required.
11.2.1 To transfer data to the Analysis Software you need to do these three
steps first:
Step 1: Installing the AMD-Tek or Swann USB-Ethernet adapter. Safety, Care and
Maintenance:
1. Insert the supplied AMD-Tek or Swann USB-Ethernet adapter into a spare
USB slot on your computer.
2. Your computers operating system will automatically detect and install the
drivers for the adapter.
