PC-POD-CP-010-v01 Printed copies are not controlled. Page 9 of 14
NOTE: Measurements can be done on either the right or left side, but do not mix sides.
Consistent measurement practices and electrode placement are important to obtain
accurate results.
10.7 Clean the sites with an alcohol swab.
10.8 Allow sites to dry for 30 seconds before placing electrodes.
10.9 Place electrodes, with tabs pointing away from body, ensuring that they are
5 cm apart measured from the center to center (a 1-cm displacement of
electrodes can result in a 2-percent change in resistance). Do not press
down on the electrodes too firmly.
10.10 Attach lead wires to electrode tabs.
NOTE: Ensure that the metallic part of clip is in direct contact with the conductor side
(underside) of the electrode tab and that the clips are aligned to the centers of the
electrode tabs.
10.11 Click “Measure” in main menu.
10.12 Click on the box under “File Name” and enter participant ID and press
“Ok”.
10.13 Click on “Edit” under “Patient Details”.
10.14 Enter information and click “Ok”.
