Cheetah Pregius Camera with Camera Link – User Manual
July 6, 2018 Page 56 of 64 Rev 1.1
Address
Register Name
Data
Type
Usage
Data (31:2)
N/A
0x0014
Aoi_HwM_Ofs
Data (12:0)
<value> MAOI offset in
horizontal direction
Data (31:13)
N/A
RW
Sets Master AOI
Horizontal offset.
0x0018
Aoi_HwM_Wdt
Data (12:0)
<value> MAOI width in
horizontal direction
Data (31:13)
N/A
RW
Sets Master AOI
Horizontal size.
0x001C
Aoi_VwM_Ofs
Data (12:0)
<value> MAOI offset in
vertical direction
Data (31:13)
N/A
RW
Sets Master AOI
Vertical offset.
0x0020
Aoi_VwM_Hgh
Data (12:0)
<value> MAOI height in
vertical direction
Data (31:13)
N/A
RW
Sets Master AOI
Vertical size.
0x0024
Hrz_Decim_En
Data (0)
0x0 – Horizontal
Decimation disable
0x1 – Horizontal
Decimation enable
Data (31:1)
N/A
RW
Sets Horizontal
Subsampling 2:1.
0x0028
Ver_Decim_En
Data (0)
0x0 – Vertical Decimation
disable
0x1 – Vertical Decimation
enable
Data (31:1)
N/A
RW
Sets Vertical
Subsampling 2:1.
0x002C
Ver_Bin_En
Data (0)
0x0 – No Vertical Binning
0x1 – 2x Vertical Binning
Data (31:1)
N/A
RW
Vertical Binning
2:1 Mode Enable.
0x0030
Img_Hrev_en
Data (0)
0x0 – Horizontal Flip
Disable
0x1 – Horizontal Flip
enable
Data (31:1)
N/A
RW
Flips image left to
right.
0x0034
Img_Vrev_en
Data (0)
0x0 – Vertical Flip Disable
0x1 – Vertical Flip enable
Data (31:1)
N/A
RW
Flips the image
upside down.
0x0038
BLK_Adj_en
Data (0)
0x0 – enable user black
level correction
0x1 – Auto black level
correction
Data (31:1)
N/A
RW
Enables the black
level correction.
0x003C
BLK_Adj_Value
Data (7:0)
<value> -- Black level
value
Data (31:8)
N/A
RW
Sets black Level
value.
0x0040
Exp_Ctl_Mod
Data (1:0)
0x0 – off – no exposure
control
0x1 – pulse width – for
triggering
0x2 – internal – exposure
control
0x3 – N/A
Data (31:2)
N/A
RW
Sets Exposure
control mode.
0x0044
Exp_Tim_Abs
Data (23:0)
<value> -- actual exposure
time in micro-seconds
Data (31:1)
N/A
RW
Sets Exposure
time.
