Cheetah Pregius Camera with Camera Link – User Manual
July 6, 2018 Page 8 of 64 Rev 1.1
The cameras are suitable in a wide range of environmental conditions and applications,
such as machine vision, industrial inspection, high-definition surveillance, aerospace, and
more.
1.1.1 Key Features
• Global shutter
• High frame rates
• Internal, external exposure controls
• Automatic gain and exposure control (AEC/AGC)
• Two Areas of Interest (AOI)
• Camera Link interface
• Two strobe outputs
• Trigger inputs
• Automatic and manual white balance
• Binning and sub-sampling
• Dynamic transfer function and gamma corrections
• field upgradeable firmware
1.2 Technical Specifications
1.2.1 C2020 and C2420 Cameras
Specifications
C2020 – 3.1 MP
C2420 – 5 MP
Active image resolution
2064 (H) x 1544 (V)
2464 (H) x 2056 (V)
Pixel size
3.45 μm
3.45 μm
Optical format
1/1.8 inch
2/3 inch
Shutter
Global
Global
Frame rate (max)
148 (8-bit), 121 (10-bit), 54
(12-bit)
97 (8-bit), 79 (10-bit), 35 (12-
bit)
Digitization
8-bit, 10-bit, 12-bit
8-bit, 10-bit, 12-bit
Pixel Clock rate
37.125MHz
37.125MHz
Dynamic range
71 dB
71 dB
Shutter speed
1 µs/step, 14 µs to 16.0 sec
1 µs/step, 14 µs to 16.0 sec
Analog / Digital gain
0-48 dB (0.1 dB step)
0-48 dB (0.1 dB step)
Auto gain/exposure
Yes
Yes
Black level offset
Yes
Yes
Binning
1x2, 2x1 and 2x2
1x2, 2x1 and 2x2
Sub-sampling
1x2, 2x1 and 2x2
1x2, 2x1 and 2x2
White balance
Once, Manual, Auto
Once, Manual, Auto
Trigger inputs
External, pulse generator,
software, computer
External, pulse generator,
software, computer
Trigger options
Edge, Overlap
Edge, Overlap
Trigger modes
Standard, Fast
Standard, Fast
