Cheetah Pregius Camera with Camera Link – User Manual
July 6, 2018 Page 55 of 64 Rev 1.1
Address
Register Name
Data
Type
Usage
0x6094
Wbc_Red,
Wbc_Green
Data (11:0)
Current Red WBC
Data (23:12)
Current Green WBC
Data (31:24)
N/A
RO
Returns current white
balance coefficient
values for Red and
Green.
0x6098
Wbc_Blue,
wbc_White
Data (11:0)
Current Blue WBC
Data (23:12)
Current White WBC
Data (31:24)
N/A
RO
Returns current white
balance coefficient
values for Blue and
White.
0x60A0
Agc_Lum_Agn
Data (11:0)
Current Analog Gain
Data (23:12)
Current Average
Luminance
Data (25:24)
Gain
Max(25)/Min(24)
Limit Reached
Data (27, 26)
N/A
Data (29:28)
Exposure
Max(29/Min(28)
Limit Reached
Data (31, 30)
N/A
RO
Returns current analog
gain and current
average image
luminance during
normal and AGC
operation.
EEPROM Space
Address
Register Name
Data
Type
Usage
0x5000
Boot User Set
Default Selector
Data (2:0)
0x0 – Boot from Factory
0x1 – Boot from User #1
0x1 – Boot from User #2
0x1 – Boot from User #3
0x1 – Boot from User #4
0x5 or 0x7 – reserved
Data (31:3)
RW
Determines
configuration
space (factory,
user #1 -- user #4)
to load in camera
after a power
cycle or reset
(‘SW_Reset’)
command.
Factory/User1/User2/User3/User4 FLASH Store
Sony IMX xxx Registers
Address
Register Name
Data
Type
Usage
0x0000
IMX_Analog_Ga
in
Data (8:0)
<value> -Gain setting with
0.1dB per step to 48dB
Data (31:9)
N/A
RW
Sets Analog Gain:
0 -- 48 dB; 0.1 dB
step
0x0008
IMX_A2D_Bits
Data (1:0)
0x0 – 8 bits
0x1 – 10 bits
0x2 –12 bits
Data (31:4)
N/A
RW
Sets number of
IMX A/D
conversion bits
per Sony.
0x0010
AOI_Control
Data (1:0)
0x0 – MAOI disable
0x1 – MAOI enable with
frame rate increase
0x2 – MAOI enable with
constant frame rate
RW
Controls AOI
parameters.
