Imperx Cheetah C2020 - Miscellaneous Registers

Cheetah Pregius Camera with Camera Link – User Manual
July 6, 2018 Page 64 of 64 Rev 1.1
Address
Register Name
Data
Type
Usage
0x0F – Frame Pulse
Data (31:8)
N/A
Miscellaneous Registers
Address
Register Name
Data
Type
Usage
0x0604
Baud_rate_sel
Data (2:0)
0x0 – 9600
0x1 – 19200
0x2 – 38400
0x3 – 57600
0x4 – 115200 (default)
0x5 to 0x7 - reserved
Data (31:3)
N/A
RW
RS-232 Baud Rate
Selector 0=9600,
1=19200,
2=38400, 3=57600
and 4=115200 bps
0x060C
RGS_ID#_Register
RW
Contains RGS ID
number register.
