Cheetah Pregius Camera with Camera Link – User Manual
July 6, 2018 Page 63 of 64 Rev 1.1
Address
Register Name
Data
Type
Usage
0x054C
Pls_Gen_Per
Data (23:0)
<value> –Sets Pulse period
in microseconds when
multiplied by granularity
setting
Data (31:24)
N/A
RO
Sets the value of
the pulse period in
microseconds.
0x0550
Pls_Gen_Nmb
Data (15:0)
<value> – number of
discrete pulses
Data (16)
0x1 – continuous pulse
generation
Data (31:17)
N/A
RW
Sets the number
of the pulses
generated. If Bit
16 is set,
continuous mode
selected.
0x0554
Pls_Gen_En
Data (0)
0x0 – disable Pulse Gen
0x1 – enable Pulse Gen
Data (31:1)
N/A
RW
Enables pulse
generator.
0x0558
OUT1_Pol_sel
Data (0)
0x0 – active LOW
0x1 – active HIGH
Data (31:1)
N/A
RW
Selects OUT1
polarity (active
Low or High).
0x055C
OUT1_Map_Sel
Data (7:0)
0x00 – no mapping
0x01 – exposure start
0x02 – exposure end
0x03 – mid exposure
0x04 – active exposure
window
0x05 – H sync
0x06 – V sync
0x07 – odd/even frame flag
0x08 – trigger pulse actual
0x09 – trigger pulse delayed
0x0A – camera ready
0x0B – pulse generator
0x0C – strobe #1
0x0D – strobe #2
0x0E – toggle OUT 1
0x0F – Frame pulse
Data (31:8)
N/A
RW
Maps the various
internal signals to
OUTPUT # 1 (OUT
1).
0x0560
OUT2_Pol_sel
Data (0)
0x0 – active LOW
0x1 – active HIGH
Data (31:1)
N/A
RW
Selects OUT2
polarity (active
Low or High).
0x0564
OUT2_Map_Sel
Data (7:0)
0x00 – no mapping
0x01 – exposure start
0x02 – exposure end
0x03 – mid exposure
0x04 – active exposure
window
0x05 – H sync
0x06 – V sync
0x07 – odd/even frame flag
0x08 – trigger pulse actual
0x09 – trigger pulse delayed
0x0A – camera ready
0x0B – pulse generator
0x0C – strobe #1
0x0D – strobe #2
0x0E – toggle OUT 1
RW
Maps the various
internal signals to
Output #2 (OUT 2)
