3.4.2 COMMUNICATIONSPECIFICATIONS
Toseecommunicationfunctionsseechapter:5.1Controlandfunctions.Someofthefunctionsareavailableonly
onNMT(D)MAXC.Detailedspecificationsaboutusedprotocolsaredescribedincommunicationsmanual.
3.4.3 ANALOGINPUTSANDOUTPUTS
OnlyavailableonNMT(D)MAXC.
Connectionscanbeusedeitherasinputsoroutputs,dependingonhowwesetit.Pumphas3connectors:SET1,
SET2andSET3.

3.4.4 RELAYOUTPUT
AvailableonlyonNMT(D)MAXCpumps.

3.4.5 ETHERNET
AvailableonlyonNMT(D)MAXCpumps.




Electrical properties
Inputvoltage
–
1‐32VDC Whenusedasinput.
Outputvoltage 0‐12VDC Whenusedasanoutput.Max.5mA loadonindividualoutput.
Inputimpedance ~100kΩ 0.5mAadditionalloadformostconfigurations.
Inputsinkcurrent 0‐33mA CommonsinkonCOM,ifusedasoutput.
Galvanicisolation Voltage4kVupto1s,275Vpermanent.
Electrical properties
Ratedcurrent 3A
Maximumvoltage 230VAC,32VDC
Electrical properties
Connector RJ‐45, 10BASE‐T,10Mbit/s.
Services
‐ Webserver(port80)
‐ Softwareupdatethroughwebinterface.
‐ OptionofModbusaRTUthroughTCP/IP
DefaultIPaddress 192.168.0.245( 192.168.0.246forrightpump)
Ethernetvisual
diagnostics
LED1
Slowlyblinkingifmoduleison.Lightsupwhentheconnectionisestablished.
LED2
