IN-COMMAND NCTP100 User Manual

• SPECIFICATIONS
BLE TPMS SENSOR
Operating Voltage 3V
Operating Humidity 95 % MAX
Operating Current
＜15 mA at DC 3V
Storage Temperature -40˚F to 185 ˚F
Operating Temperature -4 ˚F to 185 ˚F
Monitored Pressure Range 0 to 184 psi
Monitored Temperature Range -4 ˚F to 185 ˚F
Operating Frequency 2.4GHz
Transmission Power 4 dBm MAX
Battery Life 1 year (under normal operating condition)
Battery Capacity 130 mAh (CR1632)
Weight 10 g ± 0.5 g (including battery)
REPEATER SENSOR
Operating Voltage 12V/24V
Operating Humidity 90 % MAX
Storage Temperature -40 ˚F to 257 ˚F
Operating Temperature -4 ˚F to 185 ˚F
Operating Frequency Bluetooth Low Energy 4.0, 2400MHz~2483.5MHz
Transmission Power 4 dBm MAX
Receiver Sensitivity < -85dBm
Modulation format GFSK
Operating Current 40mA Max. @ DC 12V

IN-COMMAND NCTP100 Specifications

General

Brand	IN-COMMAND
Model	NCTP100
Category	Automobile Accessories
Language	English
