Register
Address:
Decimal
[hex]
Class & Type Function: Binary Format:
46145
[1800]
Class:
Configuration
Type:
Read\write
On-tap guard
band limit
dddddddddddddddd
“d” = tenths of a degree
(in binary)
46146
[1801]
Class:
Configuration
Type:
Read\write
On-tap alarm
relay
00000000000000 rr
LSBs (rr)
00 – OFF
01 – LO Relay
10 – HI Relay
46147
[1802]
Class:
Configuration
Type:
Read\write
Reference year
for On-tap
counter
0000yyyyyyyyyyyy
“y” = Year
(in binary)
46148
[1803]
Class:
Configuration
Type:
Read\write
Reference date
for On-tap
counter
0000mmmm 000ddddd
“m” = Month
“d” = Day
(in binary)
46401,
46402
[1900,
1901]
Class:
Configuration
Type:
Read\write
Change up-to /
down-to counter
limit
seeeeeeeemmmmmmm MSW
mmmmmmmmmmmm LSW
IEEE 754-1985 single precision float
MSW = [1900] LSW = [1901]
(in thousands of counts)
46403
[1902]
Class:
Configuration
Type:
Read\write
Change up-to /
down-to counter
alarm relay
00000000000000 rr
LSBs (rr)
00 – OFF
01 – LO Relay
10 – HI Relay
46404
[1903]
Class:
Configuration
Type:
Read\write
Reference year
for up-to /
down-to counter
0000yyyyyyyyyyyy
“y” = Year
(in binary)
46405
[1904]
Class:
Configuration
Type:
Read\write
Reference date
for up-to /
down-to counter
0000mmmm 000ddddd
“m” = Month
“d” = Day
(in binary)
