Incon 1250-LTC - Page 31

31
Register
Address:
Decimal
[hex]
Class & Type Function: Binary Format:
46657
[1A00]
Class:
Configuration
Type:
Read\write
Pass-through-
neutral limit
dddddddddddddddd
“d” = tenths of a day
(in binary)
46658
[1A01]
Class:
Configuration
Type:
Read\write
Pass-through-
neutral counter
alarm relay
00000000000000 rr
LSBs (rr)
00 – OFF
01 – LO Relay
10 – HI Relay
46913
[1B00]
Class:
Configuration
Type:
Read\write
One-direction
counter limit
0000000000ssssss
LSBs(ssssss)
6-bits, number of taps
46914
[1B01]
Class:
Configuration
Type:
Read\write
One-direction
counter alarm
relay
00000000000000 rr
LSBs (rr)
00 – OFF
01 – LO Relay
10 – HI Relay
47169
[1C00]
Class:
Configuration
Type:
Read\write
Low tap relay
limit
ssssssssssssssss
16-bit signed word, low tap limit
47170
[1C01]
Class:
Configuration
Type:
Read\write
Low tap alarm
relay
00000000000000 rr
LSBs (rr)
00 – OFF
01 – LO Relay
10 – HI Relay
47425
[1D00]
Class:
Configuration
Type:
Read\write
High tap relay
limit
ssssssssssssssss
16-bit signed word, high tap limit
47426
[1D01]
Class:
Configuration
Type:
Read\write
High tap alarm
relay
00000000000000 rr
LSBs (rr
)
00 – OFF
01 – LO Relay
10 – HI Relay
