Incon 1250-LTC - Page 32

32
Register
Address:
Decimal
[hex]
Class & Type Function: Binary Format:
47938
[1F01]
Class:
Configuration
Type:
Read\write
Tap change
acknowledge
relay
00000000000000 rr
LSBs (rr
)
00 – OFF
01 – LO Relay
10 – HI Relay
47939
[1F02]
Class:
Configuration
Type:
Read\write
Acknowledge
relay delay time
000000000sssssss
“s” = Delay in tenths of a second
47940
[1F03]
Class:
configuration
Type:
Read\write
Acknowledge
relay duration
time
000000000sssssss
“s” = Duration in tenths of a second
48193
[2000]
Class:
Configuration
Type:
Read\write
“FA 25” error
relay
00000000000000 rr
LSBs (rr)
00 – OFF
01 – LO Relay
10 – HI Relay
48194
[2001]
Class:
Configuration
Type:
Read\write
“FA 27” error
relay
00000000000000 rr
LSBs (rr)
00 – OFF
01 – LO Relay
10 – HI Relay
48705
[2200]
Class: State
Type:
Read\write
Tap index select 00000000 uuuuuuuu
Unsigned byte Zero-based index of tap
( value <= 39 decimal)
** NOTE: ALWAYS initially write the
tap index select register before reading
any of the tap attribute registers 0x3001
through 0x3007; that single write will
suffice until it’s desired to select a
different tap index, at which time another
write of the new tap index to this register
is required. Also write this register if a
restart may have occurred since the last
write; i.e. the value of tap index select is
not retained over a reset.
