Register
Address:
Decimal
[hex]
Class & Type Function: Binary Format:
48706
[2201]
Class: State
Type: Read-only
Tap number
corresponding
to Tap index
select
ssssssssssssssss
Signed 16-bit word
48707
[2202]
Class: State
Type: Read-only
Neutral number
corrresponding
to Tap index
select
uuuuuuuuuuuuuuu
Unsigned 16-bit word
48708
[2203]
Class: State
Type: Read-only
Max On-Tap
deviation
corresponding
to Tap index
select
ssssssssssssssss
Signed 16-bit word denoting tenths of a
degree
48709,
48710
[2204,
2205]
Class: State
Type: Read-only
Upper and lower
words of Up-to
count
corresponding
to Tap index
select
uuuuuuuuuuuuuuuu MSW
uuuuuuuuuuuuuuuu LSW
Unsigned 32-bit longword denoting up-
to count.
MSW = [3004] (upper)
LSW = [3005] (lower)
** NOTE: To obtain a consistent 32-bit
value, ALWAYS read 0x3004 BEFORE
0x3005; DO NOT read or write any
other register address between these
reads.
48711,
48712
[2206,
2207]
Class: state
Type: Read-only
Upper and lower
words of
Down-to count
corresponding
to
Tap index select
uuuuuuuuuuuuuuuu MSW
uuuuuuuuuuuuuuuu LSW
Unsigned 32-bit longword denoting
down-to count
MSW = [3006] (upper)
LSW = [3007] (lower)
** NOTE: To obtain a consistent 32-bit
value, ALWAYS read 0x3006 BEFORE
0x3007; DO NOT read or write any
other register address between these
reads.
