Materials and Tools Required Page 2.0 - 1 2.0
2.0 TS-LLD Materials & Tools
Required
Do a Site Survey Before Attempting the Installation
Submersible Turbine Pumps:
What is the Motor Control / Pump Relay Box or Starter Type ? and
What is the Model Number, HP, Manufacturer, and age of all Turbine Pumps ?
Electrical Supply:
What is the Voltage and Phase (240 VAC – Single or Three Phase ? ) of all
Turbine Pumps ?
Materials Required
❒
Petroleum absorbent / absorbing rags
❒
Pipe Dope — Non-hardening (Soft-Set), UL Classified, gas/oil resistant —
to seal the Leak Sensing Unit, and the 1/4 inch Tank Test Port plug at the pump
❒
MI Cable Adapter — for installation on the TS-LLD Leak Sensing Unit (LSU). The
TS-RJ 2" NPT Cable Adapter for Red Jacket
®
submersible pumps is
(supplied
with the TS-LLD),
the adapter for FE Petro
®
STPs must be ordered separately...
Order INCON part number:
TS-FE 3" straight Cable Adapter for FE Petro
®
STPs
*
❒
Stick-on
DANGER
labels
(INCON P/N 240-1175 – supplied with the TS-LLD)
❒
(1) 1/4 inch NPT pipe plug for the tank test port at the pump head
(supplied with
the TS-LLD)
❒
Red wire nuts for LSU wiring at the pump head
(supplied with the TS-LLD)
❒
(1) 1µ Farad Line Filter capacitor for the pump relay box
(INCON P/N 020-0028
– supplied with the TS-LLD)
❒
Wire: 14 AWG, 3 feet
(supplied with the TS-LLD)
❒
(6) spade lugs for #8 studs to connect the 14 AWG wire at the pump relay box
Contents:
• Do a Site Survey Before Attempting the Installation
• Materials Required
• Tools Required
