3 Page 3 - 4 TS-LLD INSTALLATION GUIDE
CU Component Location & Function (Continued... )
Line Leak Test light
➁
Turns on when any line leak test starts and stays on during the entire test. The light
only turns off when:
1) a test finishes
2) a dispense occurs
3) the Reset Test button is pushed
Line Leak Detected light
➂
Flashes on and off continuously when a line leak test fails. This light will continue to
flash until another test – of equal or greater precision – finally passes.
Display Functions, Codes & Concise Instructions
➃
RESET TEST touch button
➄
... press to:
• Abort, Stop, or Cancel any line leak test (the Line Leak Test light
➁
will also
turn off when the RESET TEST is pushed)
• Clear any flashing Error codes and Enable product dispensing (except the
Flashing 83 or 84 Error codes)... error codes will reappear if the problem remains
• Reset and restart automatic line leak testing (the leak detected light
➂
cannot
be reset if a leak was detected)...
Automatic Line Leak Tests resume after product
is dispensed.
• Perform a Self-Test (one push displays an
88
) see Chapter - Section 6.1
• Display diagnostic codes (see Chapter - Section 6.1)
• Start a manual, 0.1 gph annual precision line leak test
Display Diagnostic Test Codes:
See Chapter - Section 6.1 for directions about Diagnostic Display Test Codes
Starting a Manual 0.1 gph Precision Leak Test
Requirements:
Prevent dispensing / bag dispenser during this time. The manual test needs 4
hours of quiet-time BEFORE it is started, and takes about 13 minutes to finish.
Definition:
quiet-time is the inactive period –between– product dispensing
NOTE
☞
NOTE
☞
