System Operation & Testing Page 3 - 5 3
A Flashing 80 Error code will be produced, and dispensing inhibited, if a dispense
is attempted when an annual test is running. This error can be cleared by pushing
the RESET-TEST touch button.
How to Start a Manual Test
Press and hold the RESET-TEST touch button down more than 5 seconds until
the Line Leak Test light
➁
turns on. Do not hold the reset-test button down
longer than 4 seconds unless a manual test is desired.
Normal Operation – Sequence of Events / Steps
1.) Product Dispense – Begin
( dispenser: nozzle out / lever up / switch on )
a) Aborts / Cancels / Stops any line leak test that is running, and turns off the Line
Leak Test light
➁
– or –
b) Perform a functional self-check and allow product dispensing IF okay
– or –
c) Prevent dispensing (turn the pump off) IF an error or fault was detected
2.) Product Dispense – End
( dispenser: nozzle in / lever down / switch off )
After a short delay the 3.0 gph line leak test starts.
3.) The 3.0 gph Gross Hourly Test
Starts automatically — after every dispense and before a 0.2 gph test, or before a
0.1 gph test.
a) The 3.0 gph hourly test takes about 3 minutes of quiet-time to finish
b) The Line Leak Test light
➁
stays on throughout this test
c) The process will begin again from
Step 1.) when Product is Dispensed
4.) The 0.2 gph Monthly-Compliance Test
a) Requires from 13 minutes – to – 4 hours of uninterrupted quiet-time to finish
The total time required to complete the monthly test depends on the specific
conditions at the site and within the line. Tests finish rather quickly when an
obvious pass or fail condition exists. Tests times are lengthened when a more
detailed analysis is required.
b) The 0.2 gph test is made up of one or more, 13-minute test-cycles.
)
c) The Line Leak Test light
➁
stays on throughout the entire test
NOTE
☞
NOTE
☞
