This chapter contains instructions ranging from routine cleaning to maintenance
inspections, replacement instructions, and
maintenance frequency
...
A/R means
as required.
Replacement part numbers are shown here as well.
Cleaning the Control Unit
Clean the Control Unit (CU) exterior with a soft sponge or cloth that is
slightly
dampened
with a solution of water and mild detergent
– A/R by Customer
DANGER
Fire, Explosion, & Electrical Shock Hazard. Before installing,
servicing, or working on this equipment, make sure all submersible pump
power and pump relay coil / dispenser power is turned off & locked out at
the electrical panel.
Prevent automatic or unauthorized pump start-ups, spills
from pressurized lines, and electrical shocks.
See Chapter 2.1 and follow all
Safety advise.
Control Unit Replacement Parts
Items
Frequency = A/R
Replacement Part Numbers
a) Fuse F1
.......................................................
P/N = 430-0010
b) Terminal Board ....................................................... P/N = 010-0072
c) Replacement cover faceplate (with new Software ) ........... P/N = TS-FPU
d) Entire Control Unit US.................................................. P/N = TS-CU
Canadian ....................................... P/N = TS-CU/C
Are the CU box label and cover label correctly marked with the product and line #?
Are the jumper links behind the cover (at J2) correctly configured ? Reference
Chapter 2.3 for product & jumper link configuration(s).
Pump Relay Control Box Replacement Parts
Items
Frequency = A/R
Replacement Part Numbers
Line Filter Capacitor
@
Pump Relay (Motor Control) Box ........ P/N = 020-0028
...
Contents:
• Cleaning the Control Unit
• Control Unit Replacement Parts
• Rump Relay Control Box Replacement Parts
• Leak Sensing Unit Replacement Parts
•
LSU Removal for Service / Inspection and Cleaning
• After Maintenance or Service DO
NOTE
☞
