TB SERIES
TB_SERIES_rev. 03-2011 17
USING THE REFRIGERATOR AS A FREEZER
TB31-TB31A-TB41-TB41A-TB51-TB51A
When using the equipment as freezer, please meet the load limit indicated inside the refrigerator.
ELECTRONIC CONTROL
Compressor station
Functions and features.
This is an electronic device which has the function of piloting the motor of the compressor and carrying
out all the controls and electrical protection of the system.
Its main features are as follows:
a) Protection of the battery through automatic turning off of the compressor when the feeding voltage
reaches the minimum threshold.
The compressor will start up again automatically when the voltage goes back to normal values.
Note: these values have been measured at control unit input and/or on the DC socket.
Battery protection
(SWITCH POSITION)
Cut-out 12V Cut-in 12V Cut-out 24V Cut-in 24V
LOW 9.6 10.9 21.3 22.7
MED 10.1 11.4 22.3 23.7
HIGH 11.1 12.4 24.3 25.7
ENGLISH
