Index Basic Servicemanual v 3.0
11BOX 155 • S-954 23 GAMMELSTAD • SWEDEN • PHONE +46-920 203080 • TELEFAX +46-920 203085 • www.indexbraille.com • E-MAIL info@indexbraille.com
1. 2. 3. 4. 5. 6. 7. 8.
1. 12 V Light = 12V DC Ok!
2. 40 V Light = 40V DC Ok!
3. 5 V Light = 5V DC Ok!
4. - -
5. On line Light = ON LINE
6. - -
7. Paper moving sensor On/off during printout
8. Papersensor Light = Paper IN
LED indicator
